Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home
Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home
Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home
Product Details:
Place of Origin: ShenZhen China
Brand Name: Hofon Motor
Certification: RoHS/ISO9001:2000/ISO14001/TS16949
Model Number: GM1024-N10VA
Payment & Shipping Terms:
Minimum Order Quantity: 2000PCS
Price: Negotiation
Packaging Details: Carton Box
Delivery Time: 35Days
Supply Ability: 5000KPCS/Month
Contact Now
Detailed Product Description
Voltage Range: 6V Or Customized Material: Metal Gear High Precision Gear
Diameter: 24mm No Load Speed: 85RPM
No Load Current: 65mA Rated Load Torque: 1300g.cm
Rated Load Speed: 52RPM Rated Load Current: 330mA
Gear Ratio: 298:1

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 0

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 1

Typical Applications:
- Electronic door lock / Monitor / Printer / Robot / Optic equipment / Precision instrument
- Bank equipment / Safe box / Paper feeder / Intelligent gas meter / Tissue machine
- Accessory of automobile / Ad equipment / Analysis instrument / Electronic game machine



Customized Service:

Voltage, speed, torque and other performance parameters can be customized according to requirements.

Shaft length, D-CUT shaft, threaded shaft, encoder, gear box and so on can be customized.



Representative Performance:

MODEL VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING RANGE NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT TORQUE CURRENT
r/min A r/min A mN.m g.cm w mN.m g.cm A
GM12F-N10VA-07285-30 3.0-7.0 6.0V 600 0.055 320 0.240 15 150 1.440 ≥30 ≥300 0.40
GM12F-N10VA-07285-50 3.0-7.0 6.0V 360 0.055 192 0.240 25 250 1.440 ≥50 ≥500 0.40
GM12F-N10VA-07285-100 3.0-7.0 6.0V 180 0.055 96 0.240 50 500 1.440 ≥100 ≥1000 0.40
GM12F-N10VA-07285-150 3.0-7.0 6.0V 120 0.055 64 0.240 75 750 1.440 ≥130 ≥1300 0.40
GM12F-N10VA-07285-210 3.0-7.0 6.0V 85 0.055 45 0.240 105 1050 1.440 ≥130 ≥1300 0.40
GM12F-N10VA-07285-250 3.0-7.0 6.0V 72 0.055 38 0.240 125 1250 1.440 ≥130 ≥1300 0.40
GM12F-N10VA-07285-298 3.0-7.0 6.0V 60 0.055 32 0.240 149 1490 1.440 ≥130 ≥1300 0.40
GM12F-N10VA-07285-30 3.0-5.5 3.0V 300 0.050 160 0.120 7.5 75 0.360 ≥12.9 ≥129 0.20
GM12F-N10VA-07285-50 3.0-5.5 3.0V 180 0.050 96 0.120 12.5 125 0.360 ≥21.5 ≥215 0.20
GM12F-N10VA-07285-100 3.0-5.5 3.0V 90 0.050 48 0.120 25.0 250 0.360 ≥43 ≥430 0.20
GM12F-N10VA-07285-150 3.0-5.5 3.0V 60 0.050 32 0.120 37.5 375 0.360 ≥65 ≥650 0.20
GM12F-N10VA-07285-210 3.0-5.5 3.0V 42 0.050 22 0.120 52.5 525 0.360 ≥90 ≥900 0.20
GM12F-N10VA-07285-250 3.0-5.5 3.0V 36 0.050 19 0.120 62.5 625 0.360 ≥107 ≥1075 0.20
GM12F-N10VA-07285-298 3.0-5.5 3.0V 30 0.050 16 0.120 74.5 745 0.360 ≥120 ≥1200 0.20
GM12F-N10VA-08205-30 3.0-7.0 6.0V 840 0.065 515 0.330 12.9 129 1.980 ≥32 ≥320 0.73
GM12F-N10VA-08205-50 3.0-7.0 6.0V 506 0.065 310 0.330 21.5 215 1.980 ≥53 ≥530 0.73
GM12F-N10VA-08205-100 3.0-7.0 6.0V 253 0.065 155 0.330 43 430 1.980 ≥107 ≥1070 0.73
GM12F-N10VA-08205-150 3.0-7.0 6.0V 168 0.065 103 0.330 64.5 645 1.980 ≥130 ≥1300 0.73
GM12F-N10VA-08205-210 3.0-7.0 6.0V 120 0.065 73 0.330 90.3 903 1.980 ≥130 ≥1300 0.73
GM12F-N10VA-08205-250 3.0-7.0 6.0V 100 0.065 62 0.330 107.5 1075 1.980 ≥130 ≥1300 0.73
GM12F-N10VA-08205-298 3.0-7.0 6.0V 85 0.065 52 0.330 127.4 1300 1.980 ≥130 ≥1300 0.73
GM12F-N10VA-08205-30 3.0-5.5 3.0V 415 0.050 273 0.180 7.5 75 0.890 ≥16.5 ≥165 0.37
GM12F-N10VA-08205-50 3.0-5.5 3.0V 250 0.050 164 0.180 12.5 125 0.890 ≥27.5 ≥275 0.37
GM12F-N10VA-08205-100 3.0-5.5 3.0V 125 0.050 82 0.180 24.5 250 0.890 ≥58.5 ≥585 0.37
GM12F-N10VA-08205-150 3.0-5.5 3.0V 82 0.050 54 0.180 37.5 375 0.890 ≥87 ≥870 0.37
GM12F-N10VA-08205-210 3.0-5.5 3.0V 59 0.050 39 0.180 52.5 525 0.890 ≥120 ≥1200 0.37
GM12F-N10VA-08205-250 3.0-5.5 3.0V 50 0.050 32 0.180 62.5 625 0.890 ≥130 ≥1300 0.37
GM12F-N10VA-08205-298 3.0-5.5 3.0V 41 0.050 27 0.180 74.5 745 0.890 ≥130 ≥1300 0.37




Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 2



Reduction Ratio 1 : 3 1 : 5 1 : 10 1 : 30 1 : 50 1 : 63 1 : 100 1 : 150 1 : 210 1 : 250 1 : 298 1 : 1000



Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 3



Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 4

Application

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 5

Company Profile

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 6

Hofon Precise Motor Limited was founded in the year of 2002, to the establishment of the DC micro motor, small modulus gear motor, brushless motor research and development of the manufacture and sale of customer service professional firms.
Hofon products, specialized R & D and manufacturing in consumer electronics, toys, model aircraft, security, automotive electronics and electronic equipment, office equipment to streamline the development of important pieces of the main zero.
Hofon is more conductive to customer demand, with customers to design and develop new products,specifically in the refined products focused on the needs of customers, shorten the cycle of research and development under the precondition of, and continued to enhance customer satisfaction and productivity and to create a positive Hofon customers out of the trust.

We are committed to the Company's production of the motor and gear components with high quality and reasonable price, fast delivery and high satisfaction of marketing services around the world.

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 7


Competitive Advantage

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 8

  • 20 years experience in manufacturing motor and gearbox motor
  • Experienced Staff: average 15 years experience in R&D , ODM & OEM
  • International Approvals: ROHS/ISO9001/ISO14001/SGS/TS16949
  • Competitive Price
  • High Product Performance: Low noise, High efficiency, Long lifespan
  • Prompt Delivery: 20-25 working days after payment
  • Quality Approvals
  • Small Orders Accepted
  • Advanced equipments: Automatic winding machine, stator automatic setting machine, end cover automatic setting machine, automatic soldering machine, etc



Quality Cotrol Test


  • Reliability Test & Laboratory
  • Noise Test
  • Water-proof Test
  • Life Test
  • Impact Test
  • Storage Test
  • Salt Spray Test
  • Environmental Related Substance

Certifications

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 9



Exhibition

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 10



Packaging & Shipping

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 11

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 12

Hofon Motor GM1024-N10VA Low Rpm 3V 5V 6V 12V DC Metal Gear Motor With Gear Box For Smart Home 13
