Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA

Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA

  • Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA
Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA
Product Details:
Place of Origin: ShenZhen China
Brand Name: Hofon
Certification: RoHS/ISO9001:2000/ISO14001/TS16949
Model Number: GM12-N20VA
Payment & Shipping Terms:
Minimum Order Quantity: 2000PCS
Price: Negotiation
Packaging Details: Carton Box
Delivery Time: 35Days
Supply Ability: 5000KPCS/Month
Contact Now
Detailed Product Description
Voltage Range: 5V Or Customized Material: Metal Gear High Precision Gear
Diameter: 12mm No Load Speed: 98RPM
No Load Current: 32mA Rated Load Torque: 422g.cm
Rated Load Speed: 77RPM Rated Load Current: 122mA
Gear Ratio: 150:1
High Light:

worm drive dc motor

,

dc worm drive motor

12mm Metal Gear-box motor DC Gear Motor Low Noise and Large Torque 5V / 6V High precision gear



  • DC Worm Gear-Box Motor
  • Diameter : Φ12.0mm
  • Output : APPROX 0.1~1.0W
  • Noise Level : Less than 50dB
  • Low noise, stable performance, quality assurance


Typical Applications


  • Fully automatic electronic door lock

  • Office Automatic Equipments
  • Printer/paper Feeder
  • Bank Equipments Safe Box
  • Ad Equipment
  • Analysis Instrument/electronic
  • Game Machine
  • Household Appliances
  • Electronic Door Lock


Specifications

The following specifications are only representative of one of our models. Other performance parameters can be customized according to customer requirements



Reduction Ratio 1 : 3 1 : 5 1 : 10 1 : 30 1 : 50 1 : 63 1 : 100 1 : 150 1 : 210 1 : 250 1 : 298 1 : 1000



MODEL VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING RANGE NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT TORQUE CURRENT
r/min A r/min A mN.m g.cm w mN.m g.cm A
GM12F-N20VA-08260-150 3.0-6.0 5.0V 98 0.032 77.4 0.122 41.4 422.1 0.335 197.1 2010 0.46
GM12F-N20VA-10155-298 4.0-7.0 6.0V 75 0.045 62.3 0.224 144.0 1469 0.938 847.3 8642 1.10
GM12F-N30VA-12120-1000 3.0-6.0 5.0V 15 0.080 11.9 0.303 642.4 6552 0.800 3058.8 31200 1.14
GM12F-N30VA-11130-30 4.0-7.0 6.0V 590 0.050 484 0.225 15.9 162 0.800 88.2 900 1.02


Drawing


Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA 0


Product Details Show


Precision High Torque Worm Gear Motor , 12mm Diameter Worm Drive Motor GM12-N20VA 1

Quality Cotrol Test


  • Reliability Test & Laboratory
  • Noise Test
  • Water-proof Test
  • Life Test
  • Impact Test
  • Storage Test
  • Salt Spray Test
  • Environmental Related Substance
