Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed

Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed

    • Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed
  • Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed

    Product Details:

    Place of Origin: ShenZhen China
    Brand Name: Hofon
    Certification: RoHS/ISO9001:2000/ISO14001/TS16949
    Model Number: GM25-330CH+EN

    Payment & Shipping Terms:

    Minimum Order Quantity: 2000PCS
    Price: Negotiation
    Packaging Details: Carton Box
    Delivery Time: 35Days
    Supply Ability: 5000KPCS/Month
    Contact Now
    Detailed Product Description
    Voltage Range: 6V Or Customized Material: Metal Gear High Precision Gear
    Diameter: 25mm No Load Speed: 14RPM
    No Load Current: 50mA Rated Load Torque: 4100g.cm
    Rated Load Speed: 11RPM Rated Load Current: 220mA
    Gear Ratio: 286:1
    High Light:

    worm gear motor

    ,

    dc worm drive motor

    25mm With Hall Encoder 5V / 6V / 12V Metal Gear-box motor DC Gear Motor For Robot


    • DC Worm Gear-Box Motor
    • Diameter : Φ25.0mm
    • Output : APPROX 0.1~1.0W
    • Noise Level : Less than 50dB
    • Low noise, stable performance, quality assurance


    Typical Applications


    • Fully automatic electronic door lock

    • Office Automatic Equipments
    • Printer/paper Feeder
    • Bank Equipments Safe Box
    • Ad Equipment
    • Analysis Instrument/electronic
    • Game Machine
    • Household Appliances
    • Electronic Door Lock


    Specifications

    The following specifications are only representative of one of our models. Other performance parameters can be customized according to customer requirements


    Reduction Ratio1 : 9.61 : 26.91 :351 : 471 : 781 : 1031:1301:1721:2271:2861:3781:499



    MODELVOLTAGENO LOADAT MAXIMUM EFFICIENCYSTALL
    OPERATING RANGENOMINALSPEEDCURRENTSPEEDCURRENTTORQUEOUTPUTTORQUECURRENT
    r/minAr/minAmN.mg.cmwmN.mg.cmA
    GM25-370CH-16240-286+EN5.0-8.06.0V140.050110.22040141000.4802196.0224000.93




    Drawing


    Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed 0

    Product Details Show


    Metal DC Worm Drive Motor , Small Worm Gear Motor 50mA 14RPM No Load Speed 1
    Quality Cotrol Test


    • Reliability Test & Laboratory
    • Noise Test
    • Water-proof Test
    • Life Test
    • Impact Test
    • Storage Test
    • Salt Spray Test
    • Environmental Related Substance

    Competitive Advantage

    • 16 years experience in manufacturing motor and gearbox motor
    • Experienced Staff: average 12 years experience in R&D , ODM & OEM
    • International Approvals: ROHS/ISO9001/ISO14001/SGS/TS16949
    • Competitive Price
    • High Product Performance: Low noise, High efficiency, Long lifespan
    • Prompt Delivery: 20-25 working days after payment
    • Quality Approvals
    • Small Orders Accepted
    • Advanced equipments: Automatic winding machine, stator automatic setting machine, end cover automatic setting machine, automatic soldering machine, etc
