6 Volt Metal DC Worm Drive Motor Fully Automatic Electronic Door Lock GM1024-N10VA

6 Volt Metal DC Worm Drive Motor Fully Automatic Electronic Door Lock GM1024-N10VA

    • 6 Volt Metal DC Worm Drive Motor Fully Automatic Electronic Door Lock GM1024-N10VA
  • 6 Volt Metal DC Worm Drive Motor Fully Automatic Electronic Door Lock GM1024-N10VA

    Product Details:

    Place of Origin: ShenZhen China
    Brand Name: Hofon
    Certification: RoHS/ISO9001:2000/ISO14001/TS16949
    Model Number: GM1024-N10VA

    Payment & Shipping Terms:

    Minimum Order Quantity: 2000PCS
    Price: Negotiation
    Packaging Details: Carton Box
    Delivery Time: 35Days
    Supply Ability: 5000KPCS/Month
    Contact Now
    Detailed Product Description
    Voltage Range: 5V Or Customized Material: Metal Gear High Precision Gear
    Diameter: 24mm No Load Speed: 98RPM
    No Load Current: 32mA Rated Load Torque: 422g.cm
    Rated Load Speed: 77RPM Rated Load Current: 122mA
    Gear Ratio: 150:1
    High Light:

    worm gear motor

    ,

    dc worm drive motor

    Typical Applications


    • Fully automatic electronic door lock

    • Office Automatic Equipments
    • Printer/paper Feeder
    • Bank Equipments Safe Box
    • Ad Equipment
    • Analysis Instrument/electronic
    • Game Machine
    • Household Appliances
    • Electronic Door Lock


    24mm 5V / 6V / 12V Metal Gear-box motor DC Gear Motor Low Noise For Door Lock Robot


    • DC Worm Gear-Box Motor
    • Diameter : Φ24.0mm
    • Output : APPROX 0.1~1.0W
    • Noise Level : Less than 50dB
    • Low noise, stable performance, quality assurance


    Specifications

    The following specifications are only representative of one of our models. Other performance parameters can be customized according to customer requirements


    Reduction Ratio1 : 31 : 51 : 101 : 301 : 501 : 631 : 1001 : 1501 : 2101 : 2501 : 2981 : 1000



    MODELVOLTAGENO LOADAT MAXIMUM EFFICIENCYSTALL
    OPERATING RANGENOMINALSPEEDCURRENTSPEEDCURRENTTORQUEOUTPUTTORQUECURRENT
    r/minAr/minAmN.mg.cmwmN.mg.cmA
    GM1024F-N10VA-07285-1503.0-7.06.0V1200.055640.24073.57501.440127.413000.40
    GM1024F-N10VA-07285-1503.0-5.53.0V600.050320.12036.83750.36063.76500.20
    GM1024F-N10VA-08205-2983.0-7.06.0V850.065520.330127.413001.980313.632000.73
    GM1024F-N10VA-08205-1003.0-5.53.0V1250.050820.18024.52500.89057.35850.37


    Drawing




    Product Details Show


    6 Volt Metal DC Worm Drive Motor Fully Automatic Electronic Door Lock GM1024-N10VA 0
    Competitive Advantage


    • 16 years experience in manufacturing motor and gearbox motor
    • Experienced Staff: average 12 years experience in R&D , ODM & OEM
    • International Approvals: ROHS/ISO9001/ISO14001/SGS/TS16949
    • Competitive Price
    • High Product Performance: Low noise, High efficiency, Long lifespan
    • Prompt Delivery: 20-25 working days after payment
    • Quality Approvals
    • Small Orders Accepted
    • Advanced equipments: Automatic winding machine, stator automatic setting machine, end cover automatic setting machine, automatic soldering machine, etc


    Quality Cotrol Test


    • Reliability Test & Laboratory
    • Noise Test
    • Water-proof Test
    • Life Test
    • Impact Test
    • Storage Test
    • Salt Spray Test
    • Environmental Related Substance
